ADR 0055 — Runtime tools share one neutral operation

  • Status: Accepted — extends the shared runner in ADR 0014, protected native registration in ADR 0048 and per-call isolation in ADR 0045
  • Date: 2026-08-07

Context

Some framework-managed operations have no HTTP path and return model-facing media. Protected MCP registration already supplied validation, lifecycle and hooks, but its handler returned an MCP envelope. The equivalent AI SDK tool had to be defined separately with raw tool(), bypassing those guarantees and duplicating identity, schemas and execution.

MCP and the AI SDK also represent rich results differently. Making either SDK envelope the domain result would couple the shared handler to one transport or force a lossy lowest-common-denominator content model.

Decision

defineRuntimeTool describes one pathless operation: name, description, OperationIdentity, input/output Zod schemas, neutral handler and an explicit MCP/Agent exposure set. Both adapters turn that definition into the existing MountableTool and execute it through the canonical runner.

The optional present.mcp and present.agent callbacks run only after a successful, output-validated call. MCP presentation may provide content and metadata, but Stitchkit owns structuredContent and isError. Agent presentation is wired to the AI SDK’s toModelOutput, preserving the neutral execute/UI result while giving the model text or file content.

Presentation requires an output schema, so its input is always the validated value. transports defaults to both surfaces. Duplicate and invalid names fail at mount, including collisions with contract tools.

MCP rawTools and direct AI SDK tool() remain explicit low-level boundaries. Calls defined there make no claim to Stitchkit lifecycle, hooks, validation or request-context guarantees.

Alternatives rejected

  • Keep separate MCP and Agent definitions. Identity and policy drift remain possible, and the Agent operation still bypasses framework audit.
  • Use MCP content as the shared result. Application and Agent code would depend on MCP wire types; output validation would target the wrong value.
  • Invent one framework media union. It would lag both SDKs and discard transport-specific metadata. Typed presentation callbacks are smaller and lossless.
  • Model pathless operations as fake contracts. A fabricated HTTP method/path would leak into routing, OpenAPI and audit semantics.

Consequences

  • One definition safely mounts on MCP, Agent or both.
  • Handler behavior and audit identity cannot drift between tool transports.
  • Multimodal transport details remain at the adapter edge.
  • Existing protected MCP handlers migrate from an MCP envelope to neutral output; there is one clean public type family and no compatibility aliases.
